Model: PF-S20 and so on
It is a passive wire stacking system with a guide channel and collecting tray. The max cable lengths can be custom.
PC-S20 work with automatic machine passive cable stacking wire stacker
Descripción
It is a passive wire stacking system with a guide channel and collecting tray. The max cable lengths can be custom.
After processing each wire, the machine sends a control signal to the wire stacker making it drop the wire from the collection tube into the collection tray.
Features:
1. Low-cost solution allowing unattended operation
2. Greatly reduces the labor involved in handling long wires
3. Passive design built for almost unlimited and trouble-free cycles
4. The handling lengths can be custom
6. Works equally well with short or long wires
Videos:
Datos técnicos
| Modelo | PC-S20 | PC-S30 | PC-S40 | PC-S50 | PC-S60 |
| Max Load Length | 2m | 3m | 4m | 5m | 6m |
| Available Cable | 0.5-120 sqmm (others can custom) | ||||
| Available Cable Dia | Max 25mm (other can customs) | ||||
| Speed Setting | 0 – 2m/s | ||||
| Fuente de alimentación | 220V / 110V | ||||
Aplicación
Work with full automatic wire cutting and stripping machine, terminal crimping machine and so on.
